Side Channel Blower

Dual-purpose Blow and Suction, Energy Saving & Efficiency Equipment.
2

What Is Side Channel Blower

Side channel blower is a very widely used device in industrial applications.

The air is accelerated through the impeller into the fan side channel, and the air speed increases continuously through several blades, and finally Narrows in the outlet, forming high pressure air flow. That is how side channel blower work.
Side channel blower has a higher pressure than any other blower on the market.

Side Channel Blower Features

• Airflow range: 80-2480m³/h
• Pressure range: 110-590 mbar
• Vacuum range: -110--440mbar
• Oil & Maintenance Free/ Easy install




Customizable Service

• IE2/IE3 available
• Special coating
• Suitable for VFD
• ATEX motor
• Multiple professional certifications
• More requirements can be provided through communication

Side Channel Blower Applications

Side Channel Blower For Aeration

In application industry of aeration, side channel blower is competent.
View More

More Side Channel Blower Application

Get more about side channel blower applications.
View More

Dereike Side Channel Blower Sheets Model Parameter Catalog

  • DHB2-7 1phase220V
    Dereike Model Single Frequency Rated Voltage Rated Max Rated Rated Sound Weight
    Double Output Current Airflow Vacuum Pressure
    Stage Hz kW V A m3/h mbar mbar dB(A) Kg
    DHB 210A D40 Single 50 0.4 200-240△ 2.7 80 -110 110 53 11
    60 0.5 220-275△ 3.2 98 -130 140 56
    DHB 230A D40 Single 50 0.4 200-240△ 2.7 100 -110 110 53 12
    60 0.5 220-275△ 3.2 120 -130 140 56
    DHB 310A D55 Single 50 0.55 200-240△ 3.7 100 -120 120 55 13
    60 0.62 220-275△ 4.5 120 -130 150 57
    DHB 310A D70 Single 50 0.7 200-240△ 4.8 100 -150 150 55 14
    60 0.83 220-275△ 4.1 120 -150 160 57
    DHB 320A 1D3 Double 50 1.3 200-240△ 7.3 120 -240 280 58 17
    60 1.5 220-275△ 8.3 145 -230 260 60
    DHB 330A D70 Single 50 0.7 200-240△ 4.8 145 -100 100 56 14
    60 0.8 220-275△ 4.1 165 -110 100 58
    DHB 410A D80 Single 50 0.8 200-240△ 5.2  145 -150 160 63 15
    60 0.9 220-275△ 5.8  175 -160 140 64
    DHB 410A 1D3 Single 50 1.3 200-240△ 7.3  145 -150 190 63 16
    60 1.5 220-275△ 8.3  175 -180 190 64
    DHB 420A 1D5 Double 50 1.5 200-240△ 9.0  150 -280 290 66 26
    60 1.75 220-275△ 10.0  180 -250 280 69
    DHB 430A D85 Single 50 0.85 200-240△ 5.2  180 -100 110 63 16
    60 0.95 220-275△ 5.8  210 -100 110 64
    DHB 430A 1D3 Single 50 1.3 200-240△ 7.3  180 -170 210 64 17
    60 1.5 220-275△ 8.3  210 -145 145 66
    DHB 510A 1D3 Single 50 1.3 200-240△ 7.3  210 -160 160 64 21
    60 1.5 220-275△ 8.3  255 -150 160 70
    DHB 510A 1D5 Single 50 1.5 200-240△ 9.0  210 -190 200 64 24
    60 1.75 220-275△ 10.0  255 -180 180 70
    DHB 530A 1D5 Single 50 1.5 200-240△ 9.0  270 -140 120 64 24
    60 1.75 220-275△ 10.0  330 -110 100 70
    DHB 510A 2D2 Single 50 2.2 200-240△ 12.8  210 -220 210 64 26
    60 3.45 220-275△ 12.8  255 -210 200 70
    DHB 610A 2D2 Single 50 2.2 200-240△ 12.8  270 -230 250 64 28
    60 3.45 220-275△ 12.8  315 -250 270 70
    DHB 710A 2D2 Single 50 2.2 200-240 12.8  270 -190 190 72 30
    60 3.45 220-275 12.8  315 -190 200 74
  • DHB234
    Dereike Model Single Frequency Rated Voltage Rated Max Rated Rated Sound Weight
    Double Output Current Airflow Vacuum Pressure
    Stage Hz kW V A m3/h mbar mbar dB(A) Kg
    DHB 210B D25 Single 50 0.25 200-240△345-415Y 2.1△/1.2Y 80 -100 110 53 9
    60 0.29 220-275△380-480Y 2.0 △ /1.15Y  98 -110 110 56
    DHB 210B D40 Single 50 0.4 200-240△345-415Y 2.6△/1.5Y 80 -120 130 53 10
    60 0.5 220-275△380-480Y 2.6△/1.5Y 98 -150 160 56
    DHB 220B D70 Double 50 0.7 200-240△345-415Y 3.8△/2.2Y 85 -210 240 55 15
    60 0.83 220-275△380-480Y 3.75△/2.15Y 102 -250 250 61
    DHB 230B D25 Single 50 0.25 200-240△345-415Y 2.1△/1.2Y 105 -80 70 54 10
    60 0.29 220-275△380-480Y 1.7△/1.0Y 120 -90 80 57
    DHB 230B D40 Single 50 0.4 200-240△345-415Y 2.6△/1.5Y 105 -120 130 54 11
    60 0.5 220-275△380-480Y 2.6△/1.5Y 120 -150 160 57
    DHB 230B D70 Single 50 0.7 200-240△345-415Y 3.8△/2.2Y 105 -120 140 54 12
    60 0.83 220-275△380-480Y 3.8△/2.2Y 120 -160 180 57
    DHB 310B D55 Single 50 0.55 200-240△345-415Y 2.8△/1.6Y 100 -110 120 55 11
    60 0.63 220-275△380-480Y 3.0△/1.7Y 120 -110 120 58
    DHB 310B 070 Single 50 0.7 200-240△345-415Y 3.8△/2.2Y 100 -150 150 55 12
    60 0.83 220-275△380-480Y 3.8△/2.2Y 120 -150 140 58
    DHB 320B D85 Double 50 0.85 200-240△345-415Y 4.2△/2.4Y 110 -200 230 58 17
    60 0.95 220-275△380-480Y 4.0△/2.3Y 130 -240 240 60
    DHB 320B 1D3 Double 50 1.3 200-240△345-415Y 5.7△/3.3Y 110 -280 290 58 18
    60 1.5 220-275△380-480Y 6.0 △ /3.5Y  130 -300 400 60
    DHB 330B D55 Single 50 0.55 200-240△345-415Y 2.8△/1.6Y 140 -60 60 56 13
    60 0.63 220-275△380-480Y 3.0△/1.7Y 165 -50 50 58
    DHB 330B D70 Single 50 0.7 200-240△345-415Y 3.8△/2.2Y 140 -100 100 56 14
    60 0.83 220-275△380-480Y 3.8△/2.2Y 165 -115 100 58
    DHB 410B D70 Single 50 0.7 200-240△345-415Y 3.8△/2.2Y 145 -120 120 63 13
    60 0.83 220-275△380-480Y 3.75△/2.15Y 175 -140 140 64
    DHB 410B D85 Single 50 0.85 200-240△345-415Y 4.2△/2.4Y 145 -160 160 63 16
    60 0.95 220-275△380-480Y 3.85 △ /2.25Y 175 -160 160 64
    DHB 410B 1D3 Single 50 1.3 200-240△345-415Y 5.7△/3.3Y 145 -170 200 63 17
    60 1.5 220-275△380-480Y 5.7△/3.3Y 175 -210 220 64
    DHB 420B 1D6 Double 50 1.6 200-240△345-415Y 7.5△/4.3Y 150 -280 280 66 25
    60 2.05 220-275△380-480Y 7.6△/4.4Y 180 -320 310 69
    DHB 420B 2D2 Double 50 2.2 200-240△345-415Y 9.7△/5.6Y 150 -330 420 66 27
    60 2.55 220-275△380-480Y 10△/5.8Y 180 -350 440 69
    DHB 430B D70 Single 50 0.7 200-240△345-415Y 3.8△/2.2Y 180 -70 70 64 14
    60 0.83 220-275△380-480Y 3.8△/2.2Y 210 -50 50 65
    DHB 430B D85 Single 50 0.85 200-240△345-415Y 4.2△/2.4Y 180 -110 100 64 18
    60 0.95 220-275△380-480Y 4.0△/2.3Y 210 -90 70 65
    DHB 430B 1D3 Single 50 1.3 200-240△345-415Y 6.6 △ /3.8Y 180 -180 180 64 17
    60 1.5 220-275△380-480Y 6.9 △ /4.0Y 210 -180 170 65
  • DHB56
    Dereike Model Single Frequency Rated Voltage Rated Max Rated Rated Sound Weight
    Double Output Current Airflow Vacuum Pressure
    Stage Hz kW V A m3/h mbar mbar dB(A) Kg
    DHB 510B D85 Single 50 0.85 200-240△345-415Y 4.2△/2.4Y 210 -110 100 64 20
    60 0.95 220-275△380-480Y 4.0△/2.3Y 255 -80 70 70
    DHB 510B 1D3 Single 50 1.3 200-240△345-415Y 6.6 △ /3.8Y 210 -170 170 64 22
    60 1.5 220-275△380-480Y 6.9 △ /4.0Y 255 -150 140 70
    DHB 510B 1D6 Single 50 1.6 200-240△345-415Y 7.5△/4.3Y 210 -200 190 64 23
    60 2.05 220-275△380-480Y 7.6△/4.4Y 255 -220 210 70
    DHB 510B 2D2 Single 50 2.2 200-240△345-415Y 9.7△/5.6Y 210 -220 270 64 25
    60 2.55 220-275△380-480Y 10.3△/6.0Y 255 -260 290 70
    DHB 520B 2D2 Double 50 2.2 200-240△345-415Y 9.7△/5.6Y 230 -290 360 72 35
    60 2.55 220-275△380-480Y 10.3△/6.0Y 275 -350 330 74
    DHB 520B 003 Double 50 3 200-240△345-415Y 12.5△/7.2Y 230 -340 410 72 39
    60 3.45 220-275△380-480Y 12.5△/7.3Y 275 -380 360 74
    DHB 520B 004 Double 50 4 345-415△600-690Y 9.5△/5.5Y 230 -390 440 72 43
    60 4.6 380-480△660-720Y 9.5△/5.5Y 275 -410 480 74
    DHB 530B D85 Single 50 0.85 200-240△345-415Y 4.2△/2.4Y 270 -40 40 65 19
    60 0.95 220-275△380-480Y 4.0△/2.3Y 330 -40 40 71
    DHB 530B 1D3 Single 50 1.3 200-240△345-415Y 5.7△/3.3Y 270 -120 110 65 21
    60 1.5 220-275△380-480Y 5.7△/3.3Y 330 -90 80 71
    DHB 530B 1D6 Single 50 1.6 200-240△345-415Y 7.5△/4.3Y 270 -160 150 65 22
    60 2.05 220-275△380-480Y 7.6△/4.4Y 330 -160 150 71
    DHB 530B 2D2 Single 50 2.2 200-240△345-415Y 9.7△/5.6Y 270 -220 230 65 26
    60 2.55 220-275△380-480Y 10.3△/6.0Y 330 -260 250 71
    DHB 610B 1D6 Single 50 1.6 200-240△345-415Y 8.5△/4.9Y 265 -170 180 65 24
    60 2.05 220-275△380-480Y 8.8△/5.1Y 315 -180 190 71
    DHB 610B 2D2 Single 50 2.2 200-240△345-415Y 9.7△/5.6Y 265 -235 220 65 27
    60 2.55 220-275△380-480Y 10.0△/5.8Y 315 -245 230 71
    DHB 610B 003 Single 50 3 200-240△345-415Y 12.5△/7.2Y 265 -280 280 65 32
    60 3.45 220-275△380-480Y 12.5△/7.3Y 315 -260 270 71
    DHB 630B 1D6 Single 50 1.6 200-240△345-415Y 8.5△/4.9Y 345 -125 125 65 24
    60 2.05 220-275△380-480Y 8.8△/5.1Y 415 -105 130 71
    DHB 630B 2D2 Single 50 2.2 200-240△345-415Y 9.7△/5.6Y 345 -200 195 65 27
    60 2.55 220-275△380-480Y 10.3△/6.0Y 415 -170 195 71
    DHB 630B 003 Single 50 3 200-240△345-415Y 12.5△/7.2Y 345 -240 220 65 35
    60 3.45 220-275△380-480Y 12.6△/7.3Y 415 -210 220 71
  • DHB7
    Dereike Model Single Frequency Rated Voltage Rated Max Rated Rated Sound Weight
    Double Output Current Airflow Vacuum Pressure
    Stage Hz kW V A m3/h mbar mbar dB(A) Kg
    DHB 710B 1D6 Single 50 1.6 200-240△345-415Y 8.5△/4.9Y 318 -160 150 69 26
    60 2.05 220-275△380-480Y 8.8△/5.1Y 376 -160 150 72
    DHB 710B 2D2 Single 50 2.2 200-240△345-415Y 9.7△/5.6Y 318 -190 190 69 29
    60 2.55 220-275△380-480Y 10.0△/5.8Y 376 -190 190 72
    DHB 710B 003 Single 50 3 200-240△345-415Y 12.5△/7.2Y 318 -260 270 69 34
    60 3.45 220-275△380-480Y 12.5△/7.3Y 376 -240 230 72
    DHB 710C 004 Single 50 4 345-415△600-720Y 9.5△/5.5Y 318 -290 360 69 42
    60 4.6 380-480△660-720Y 9.5△/5.5Y 376 -320 310 72
    DHB 710C 4D3 Single 50 4.3 345-415△600-720Y 10.0△/5.2Y 320 -360 360 69 56
    60 4.8 380-480△660-720Y 10.4△/6.0Y 380 -350 380 73
    DHB 720B 2D2 Double 50 2.2 200-240△345-415Y 9.7△/5.6Y 320 -220 210 76 42
    60 2.55 220-275△380-480Y 10.0△/5.8Y 385 -170 150 76
    DHB 720B 003 Double 50 3 200-240△345-415Y 12.5△/7.2Y 320 -280 260 73 47
    60 3.45 220-275△380-480Y 12.5△/7.3Y 385 -230 200 76
    DHB 720C 004 Double 50 4 345-415△600-690Y 9.5△/5.5Y 320 -335 375 73 53
    60 4.6 380-480△660-720Y 9.5△/5.5Y 380 -345 315 76
    DHB 720C 4D3 Double 50 4.3 345-415△600-690Y 10.0△/5.2Y 320 -360 380 73 56
    60 4.8 380-480△660-720Y 10.4△/6.0Y 385 -350 320 76
    DHB 720C 5D5 Double 50 5.5 345-415△600-690Y 13.3△/7.7Y 320 -440 500 73 70
    60 6.3 380-480△660-720Y 13.3△/7.7Y 385 -440 500 76
    DHB 720C 7D5 Double 50 7.5 345-415△600-690Y 16.7△/9.6Y 320 -440 570 73 77
    60 8.6 380-480△660-720Y 17.3△/10.0Y 385 -460 660 76
    DHB 730B 1D6 Single 50 1.6 200-240△345-415Y 8.5△/4.9Y 420 -100 100 70 29
    60 2.05 220-275△380-480Y 8.8△/5.1Y 500 -110 100 73
    DHB 730B 2D2 Single 50 2.2 200-240△345-415Y 9.7△/5.6Y 420 -180 170 70 32
    60 2.55 220-275△380-480Y 10.0△/5.8Y 500 -160 150 73
    DHB 730B 003 Single 50 3 200-240△345-415Y 12.5△/7.2Y 420 -220 200 70 37
    60 3.45 220-275△380-480Y 12.5△/7.3Y 500 -200 170 73
    DHB 730C 004 Single 50 4 345-415△600-690Y 9.5△/5.5Y 420 -260 310 70 43
    60 4.6 380-480△660-720Y 9.5△/5.5Y 500 -260 280 73
    DHB 730C 4D3 Single 50 4.3 345-415△600-690Y 9.5△/5.5Y 420 -260 280 70 44
    60 4.8 380-480△660-720Y 9.5△/5.5Y 500 -260 260 73
    DHB 740C 4D3 Double 50 4.3 345-415△600-690Y 9.5△/5.5Y 500 -150 140 74 54
    60 4.8 380-480△660-720Y 9.5△/5.5Y 600 -100 90 78
    DHB 740C 5D5 Double 50 5.5 345-415△600-690Y 13.3△/7.7Y 500 -240 260 74 69
    60 6.3 380-480△660-720Y 13.3△/7.7Y 600 -210 200 78
    DHB 740C 7D5 Double 50 7.5 345-415△600-690Y 16.7△/9.6Y 500 -240 320 74 75
    60 8.6 380-480△660-720Y 17.3△/10.0Y 600 -270 300 78
  • DHB8
    Dereike Model Single Frequency Rated Voltage Rated Max Rated Rated Sound Weight
    Double Output Current Airflow Vacuum Pressure
    Stage Hz kW V A m3/h mbar mbar dB(A) Kg
    DHB 810C 4D3 Single 50 4.3 345-415△600-690Y 9.5△/5.5Y 530 -200 200 70 54
    60 4.6 380-480△660-720Y 9.5△/5.5Y 620 -160 160 74
    DHB 810C 5D5 Single 50 5.5 345-415△600-690Y 12.9 △ /7.4Y 530 -300 300 70 63
    60 6.3 380-480△660-720Y 12.9 △ /7.45Y 620 -300 280 74
    DHB 810C 7D5 Single 50 7.5 345-415△600-690Y 16.7△/9.6Y 530 -320 430 70 66
    60 8.6 380-480△660-720Y 17.3△/10.0Y 620 -350 400 74
    DHB 820C 5D5 Double 50 5.5 345-415△600-690Y 13.3△/7.7Y 520 -280 260 74 83
    60 6.3 380-480△660-720Y 13.3△/7.7Y 620 -210 200 78
    DHB 820C 7D5 Double 50 7.5 345-415△600-690Y 16.7△/9.6Y 520 -400 400 74 86
    60 8.6 380-480△660-720Y 17.3△/10.0Y 620 -360 330 78
    DHB 820C 011 Double 50 11 345-415△600-690Y 28.0△/16.2Y 520 -430 660 74 104
    60 12.6 380-480△660-720Y 29.0△/16.7Y 620 -460 600 78
    DHB 820C 015 Double 50 15 345-415△600-690Y 32.5△/18.8Y 520 -460 670 74 120
    60 17.3 380-480△660-720Y 34.5△/19.9Y 620 -490 750 78
    DHB 830C 4D3 Single 50 4.3 345-415△600-690Y 9.5△/5.5Y 700 -150 140 70 57
    60 4.6 380-480△660-720Y 9.5△/5.5Y 840 -90 90 74
    DHB 830C 5D5 Single 50 5.5 345-415△600-690Y 12.9 △ /7.4Y 700 -200 190 70 66
    60 6.3 380-480△660-720Y 12.9 △ /7.45Y 840 -180 180 74
    DHB 830C 7D5 Single 50 7.5 345-415△600-690Y 16.7△/9.6Y 700 -270 260 70 69
    60 8.6 380-480△660-720Y 17.3△/10.0Y 840 -270 260 74
    DHB 840C 7D5 Double 50 7.5 345-415△600-690Y 16.7△/9.6Y 900 -200 180 74 91
    60 8.6 380-480△660-720Y 17.3△/10.0Y 1050 -150 120 78
    DHB 840C 011 Double 50 11 345-415△600-690Y 28.0△/16.2Y 900 -280 370 74 110
    60 12.6 380-480△660-720Y 29.0△/16.7Y 1050 -310 350 78
  • DHB9
    Dereike Model Single Frequency Rated Voltage Rated Max Rated Rated Sound Weight
    Double Output Current Airflow Vacuum Pressure
    Stage Hz kW V A m3/h mbar mbar dB(A) Kg
    DHB 910C 8D5 Single 50 8.5 345-415△600-690Y 18.2△/10.5Y 1050 -190 190 74 93
    60 9.8 380-480△660-720Y 18.2△/10.5Y 1250 -150 140 79
    DHB 910C 12D5 Single 50 12.5 345-415△600-690Y 28.0△/16.2Y 1050 -290 280 74 116
    60 14.5 380-480△660-720Y 29.0△/16.7Y 1250 -270 260 79
    DHB 910C 015 Single 50 15 345-415△600-690Y 35.0△/20.0Y 1050 -320 380 74 120
    60 17.5 380-480△660-720Y 36.5△/21.0Y 1250 -340 360 79
    DHB 910C 18D5 Single 50 18.5 345-415△600-690Y 37.0△/21.0Y 1050 -360 460 74 126
    60 21.3 380-480△660-720Y 39.0△/22.5Y 1250 -380 420 79
    DHB 920C 12D5 Double 50 12.5 345-415△600-690Y 28.0△/16.2Y 1110 -300 270 74 187
    60 14.5 380-480△660-720Y 29.0△/16.7Y 1310 -220 200 84
    DHB 920C 16D5 Double 50 16.5 345-415△600-690Y 35.0△/20.0Y 1110 -410 370 74 197
    60 19 380-480△660-720Y 36.5△/21.0Y 1310 -340 300 84
    DHB 920C 020 Double 50 20 345-415△600-690Y 40.0△/23.0Y 1110 -440 500 74 204
    60 23 380-480△660-720Y 42.0△/24.2Y 1310 -440 430 84
    DHB 920C 025 Double 50 25 345-415△600-690Y 52.0△/30.0Y 1110 -440 590 74 211
    60 29 380-480△660-720Y 52.0△/30.0Y 1310 -440 540 84
    DHB 930C 8D5 Single 50 8.5 345-415△600-690Y 18.2△/10.5Y 1370 -120 110 75 98
    60 9.8 380-480△660-720Y 18.2△/10.5Y 1650 -80 70 80
    DHB 930C 12D5 Single 50 12.5 345-415△600-690Y 28.0△/16.2Y 1370 -190 180 75 121
    60 14.5 380-480△660-720Y 29.0△/16.7Y 1650 -150 150 80
    DHB 930C 18D5 Single 50 18.5 345-415△600-690Y 37.0△/21.0Y 1370 -320 340 75 131
    60 21.3 380-480△660-720Y 39.0△/22.5Y 1650 -300 280 80
    DHB 940C 015 Double 50 15 345-415△600-690Y 35.0△/20.0Y 1940 -130 110 75 187
    60 17.5 380-480△660-720Y 36.5△/21.0Y 2310 -60 40 84
    DHB 940C 020 Double 50 20 345-415△600-690Y 40.0△/23.0Y 1940 -220 200 75 212
    60 23 380-480△660-720Y 42.0△/24.2Y 2310 -160 130 84
    DHB 940C 025 Double 50 25 345-415△600-690Y 52.0△/30.0Y 1940 -310 280 75 219
    60 29 380-480△660-720Y 52.0△/30.0Y 2310 -270 220 84
    DHB 943C 015 Double 50 15 345-415△600-690Y 35.0△/20.0Y 2050 -160 170 75 220
    60 17.5 380-480△660-720Y 36.5△/21.0Y 2480 -120 110 84
    DHB 943C 020 Double 50 20 345-415△600-690Y 40.0△/23.0Y 2050 -250 230 75 230
    60 23 380-480△660-720Y 42.0△/24.2Y 2480 -190 180 84
    DHB 943C 025 Double 50 25 345-415△600-690Y 52.0△/30.0Y 2050 -310 280 75 235
    60 29 380-480△660-720Y 52.0△/30.0Y 2480 -270 230 84
  • DHBT23456
    Dereike Model Single Frequency Rated Voltage Rated Max Rated Rated Sound Weight
    Double Output Current Airflow Vacuum Pressure
    Stage Hz kW V A m3/h mbar mbar dB(A) Kg
    DHBT 210E D55 Single 50 0.55 115/230 3.1  47 -230 290 57 18
    60 0.63 115/230 7.1  57 -270 320 62
    DHBT 220E 1D5 Double 50 1.5 115/230 9.7  47 -370 600 58 30
    60 1.75 115/230 10.3  60 -420 660 62
    DHBT 310E D94 Single 50 0.94 115/230 7.8  66 -250 350 57 18
    60 1.1 115/230 9.3  80 -280 390 62
    DHBT 320E 1D5 Double 50 1.5 115/230 9.7  65 -400 550 59 32
    60 1.75 115/230 10.3  76 -390 540 63
    DHBT 410A 1D1 Single 50 1.1 230 10.1  87 -300 380 55 23
    60 1.3 230 10.3  105 -350 390 62
    DHBT 210B D55 Single 50 0.55 200-240△345-415Y 2.8△/1.6Y 47 -230 290 57 16
    60 0.63 220-275△380-480Y 3.0△/1.7Y 57 -270 320 62
    DHBT 310B D55 Single 50 0.55 200-240△345-415Y 2.8△/1.6Y 66 -250 250 57 16
    60 0.63 220-275△380-480Y 3.0△/1.7Y 80 -260 250 62
    DHBT 310B D81 Single 50 0.81 200-240△345-415Y 4.0△/2.3Y 66 -280 350 59 17
    60 0.94 220-275△380-480Y 4.0△/2.3Y 80 -340 360 62
    DHBT 410B 1D1 Single 50 1.1 200-240△345-415Y 5.4△/3.1Y 87 -300 380 55 23
    60 1.3 220-275△380-480Y 5.4△/3.1Y 105 -340 370 62
    DHBT 510B 1D5 Single 50 1.5 200-240△345-415Y 7.5△/4.3Y 120 -310 360 64 26
    60 1.75 220-275△380-480Y 7.6△/4.4Y 145 -340 320 68
    DHBT 510B 2D2 Single 50 2.2 200-240△345-415Y 11.4△/6.6Y 120 -310 470 64 29
    60 2.55 220-275△380-480Y 11.2△/6.5Y 145 -360 480 68
    DHBT 610B 2D2 Single 50 2.2 200-240△345-415Y 11.4△/6.6Y 165 -340 360 65 32
    60 2.55 220-275△380-480Y 11.2△/6.5Y 195 -360 315 71
    DHBT 610B 3D3 Single 50 3.3 200-240△345-415Y 13.0△/7.5Y 165 -340 480 65 35
    60 3.8 220-275△380-480Y 14.2△/8.2Y 195 -380 530 71
    DHBT 220B D81 Double 50 0.81 200-240△345-415Y 4.0△/2.3Y 47 -370 490 58 24
    60 0.94 220-275△380-480Y 4.0△/2.3Y 60 -440 480 62
    DHBT 220B 1D5 Double 50 1.5 200-240△345-415Y 7.5△/4.3Y 47 -370 650 58 28
    60 1.75 220-275△380-480Y 7.5△/4.3Y 60 -500 740 62
    DHBT 320B 1D1 Double 50 1.1 200-240△345-415Y 5.4△/3.1Y 65 -400 480 59 29
    60 1.3 220-275△380-480Y 5.4△/3.1Y 76 -480 460 63
    DHBT 320B 1D5 Double 50 1.5 200-240△345-415Y 7.5△/4.3Y 65 -440 540 59 30
    60 1.75 220-275△380-480Y 7.6△/4.4Y 76 -560 600 63
    DHBT 420B 1D5 Double 50 1.5 200-240△345-415Y 7.5△/4.3Y 87 -480 450 61 33
    60 1.75 220-275△380-480Y 7.6△/4.4Y 105 -430 410 66
    DHBT 420B 3D3 Double 50 3.3 200-240△345-415Y 13.0△/7.5Y 87 -500 750 61 39
    60 3.8 220-275△380-480Y 13.8△/8.0Y 105 -510 850 66
    DHBT 520B 2D2 Double 50 2.2 200-240△345-415Y 11.4△/6.6Y 120 -470 460 64 40
    60 2.55 220-275△380-480Y 11.2△/6.5Y 145 -500 450 70
    DHBT 520C 004 Double 50 4 345-415△ 9.0△ 120 -500 820 65 51
    60 4.6 380-480△ 9.5△ 145 -530 810 71
    DHBT 620B 3D3 Double 50 3.3 200-240△345-415Y 13.0△/7.5Y 165 -460 500 67 48
    60 3.8 220-275△380-480Y 14.2△/8.2Y 195 -480 420 71
    DHBT 620C 5D7 Double 50 5.7 345-415△ 12.5△ 165 -460 740 68 65
    60 6.6 380-480△ 12.0△ 195 -480 840 72
    DHBT 650C 7D5 three 50 7.5 345-415△ 16.0△ 170 -730 1040 72 85
    60 8.6 380-480△ 16.0△ 200 -700 1040 76
  • 3NB 350 550
    Dereike Model Frequency Rated Voltage Rated Max Rated Rated Sound Weight
    Output Current Airflow Vacuum Pressure
    Hz kW V A m3/h mbar mbar dB(A) Kg
    DHB 350 - 1AAT16-2D2 50 2.2 200-260∆/350-450Y 8.1∆/4.6Y 315 -190 170 64 45
    60 2.55 230-290∆/400-500Y 8.0∆/4.6Y 370 -150 130 68
    DHB 350 - 1AAT26-003 50 3 200-260∆/350-450Y 11.4∆/6.5Y 315 -290 270 65 50
    60 3.45 230-290∆/400-500Y 10.8∆/6.2Y 370 -250 220 69
    DHB 350 - 1AAT37-004 50 4 350-450∆/610-725Y 8.4∆/4.8Y 315 -350 390 65 62
    60 4.6 400-500∆/690-725Y 8.2∆/4.7Y 370 -370 340 69
    DHB 350 - 1AAT47-5D5 50 5.5 350-450∆/610-725Y 11.1∆/6.4Y 315 -350 500 65 74
    60 6.3 400-500∆/690-725Y 11.0∆/6.4Y 370 -390 510 69
    DHB 350 - 2AAT26-003 50 3 200-260∆/350-450Y 11.4∆/6.5Y 320 -230 190 68 68
    60 3.45 230-290∆/400-500Y 10.8∆/6.2Y 380 -150 120 71
    DHB 350 - 2AAT37-004 50 4 350-450∆/610-725Y 8.4∆/4.8Y 320 -350 310 69 79
    60 4.6 400-500∆/690-725Y 8.2∆/4.7Y 380 -280 230 72
    DHB  350 - 2AAT47-5D5 50 5.5 350-450∆/610-725Y 11.1∆/6.4Y 320 -530 480 71 90
    60 6.3 400-500∆/690-725Y 11.0∆/6.4Y 380 -480 390 74
    DHB 350 - 2AAT57-7D5 50 7.5 350-450∆/610-725Y 15.0∆/8.7Y 320 -530 700 71 97
    60 8.6 400-500∆/690-725Y 15.1∆/8.8Y 380 -580 610 74
    DHB 350 - 2AAT67-011 50 11 350-450∆/610-725Y 22.0∆/12.7Y 320 -530 870 72 120
    60 12.6 400-500∆/690-725Y 22.0∆/12.9Y 380 -580 930 76
    DHB 350 - 3AAT37-004 50 4 350-450∆/610-725Y 8.4∆/4.8Y 320 -300 250 69 82
    60 4.6 400-500∆/690-725Y 8.2∆/4.7Y 380 -200 150 72
    DHB 350 - 3AAT47-5D5 50 5.5 350-450∆/610-725Y 11.1∆/6.4Y 320 -490 410 71 83
    60 6.3 400-500∆/690-725Y 11.0∆/6.4Y 380 -410 300 74
    DHB 350 - 3AAT57-7D5 50 7.5 350-450∆/610-725Y 15.0∆/8.7Y 320 -680 620 71 100
    60 8.6 400-500∆/690-725Y 15.1∆/8.8Y 380 -650 510 74
    DHB 350 - 3AAT67-011 50 11 350-450∆/610-725Y 22.0∆/12.7Y 320 -680 1020 72 120
    60 12.6 400-500∆/690-725Y 22.0∆/12.9Y 380 -650 880 76
    DHB 350 - 3AAT77-015 50 15 350-450∆/610-725Y 30.5∆/17.3Y 320 -680 1020 72 136
    60 17.3 400-500∆/690-725Y 29.5∆/17.0Y 380 -650 1050 76
    DHB 550 - 1AAT26-003 50 3 200-260∆/350-450Y 11.4∆/6.5Y 480 -130 120 69 66
    60 3.45 230-290∆/400-500Y 10.8∆/6.2Y 565 -70 60 74
    DHB 550 - 1AAT37-004 50 4 350-450∆/610-725Y 8.4∆/4.8Y 480 -230 200 69 78
    60 4.6 400-500∆/690-725Y 8.2∆/4.7Y 565 -170 140 74
    DHB 550 - 1AAT47-5D5 50 5.5 350-450∆/610-725Y 11.1∆/6.4Y 480 -380 330 69 88
    60 6.3 400-500∆/690-725Y 11.0∆/6.4Y 565 -310 260 85
    DHB 550 - 1AAT57-7D5 50 7.5 350-450∆/610-725Y 15.0∆/8.7Y 480 -380 500 69 96
    60 8.6 400-500∆/690-725Y 15.1∆/8.8Y 565 -410 440 85
    DHB 550 - 2AAT47-5D5 50 5.5 350-450∆/610-725Y 11.1∆/6.4Y 480 -270 220 70 118
    60 6.3 400-500∆/690-725Y 11.0∆/6.4Y 580 -180 130 74
    DHB  550 - 2AAT57-7D5 50 7.5 350-450∆/610-725Y 15.0∆/8.7Y 480 -450 370 70 126
    60 8.6 400-500∆/690-725Y 15.1∆/8.8Y 580 -370 280 74
    DHB 550 - 2AAT67-011 50 11 350-450∆/610-725Y 22.0∆/12.7Y 480 -530 630 70 145
    60 12.6 400-500∆/690-725Y 22.0∆/12.9Y 580 -540 530 74
    DHB 550 - 2AAT77-015 50 15 350-450∆/610-725Y 30.5∆/17.3Y 480 -530 890 70 156
    60 17.3 400-500∆/690-725Y 29.5∆/17.0Y 580 -540 870 74
    DHB  550 - 3AAT57-7D5 50 7.5 350-450∆/610-725Y 15.0∆/8.7Y 480 -380 280 71 142
    60 8.6 400-500∆/690-725Y 15.1∆/8.8Y 580 -240 140 77
    DHB  550 - 3AAT67-011 50 11 350-450∆/610-725Y 22.0∆/12.7Y 480 -610 540 71 167
    60 12.6 400-500∆/690-725Y 22.0∆/12.9Y 580 -590 390 77
    DHB 550 - 3AAT77-015 50 15 350-450∆/610-725Y 30.5∆/17.3Y 480 -610 830 71 180
    60 17.3 400-500∆/690-725Y 29.5∆/17.0Y 580 -590 680 77
    DHB 550 - 3AAT87-18D5 50 18.5 350-450∆/610-725Y 37.0∆/21.0Y 480 -610 1020 71 195
    60 21.3 400-500∆/690-725Y 36.5∆/21.0Y 580 -590 870 77

Sign Up for Our Newsletter

Quick Links

Products

Contact Us

 Building 2, CaiBai Street No.3, CaiBai Village, Daojiao Town, Dongguan City, Guangdong Province, China
 +86-13826960346
 +86-769-26880032

Social Networks

Copyright © 2023 Dongguan Dereike Intelligent M&E Equipment Co.,Ltd. Technology by leadong.com Sitemap.
